1 14

Carvin Door Hinge

Sale Price: $56
Regular Price: $80

Cyber Monday: 30% off with code “CM30”
Tags: Door Hinge not on discount

Solid brass hinge ensures smooth door movement and lasting durability — perfect for both modern and classic interiors.

Durable Solid Brass

Corrosion-resistant and long-lasting

Refined Barrel Hinge

Smooth operation with decorative finials

Secure Mounting

Eight-hole plate for stability

Protect your investment

See All Benefits

Choose your warranty

  • i
    Life isn't accident-free. A protection plan is the wiser choice.

    1-Year Manufacturer Warranty

    Comes with a 1-Year Warranty. Extend to 2, 3 or 4 years for extra coverage, including most accidents.
  • i
    Even the most durable fixtures aren't immune to the unexpected Extra coverage for the essentials.

    1 Year Extended Warranty

    $30

  • i
    Prefered by most—Three years of worry-free coverage for pennies a month.

    3 Year Extended Warranty

    $50

  • i
    Ultimate peace of mind for those who value lasting assurance and long-term confidence.

    5 Year Extended Warranty

    $100

×

What’s covered?
• Physical Impact: Accidental bumps, drops, or knocks

• Electrical Failures: Wiring issues or component malfunctions

• Corrosion Protection: Prevent rust and environmental wear

• Heat Damage: Shield against overheating and extreme temperatures

• Water Resistance: Protection from unexpected leaks or exposure

• Component Wear: Coverage for mechanical parts over time


Next slide: How to file a claim →

Stress-free claims, instant replacements:

Filing a claim is quick, hassle-free, and completely paperless.


How it works:

  1. Reach out via live chat or email at help@residencesupply.com.
  2. Provide your order number and damage evidence.
  3. Your new product ships immediately and arrives in 3-5 days.

Estimated arrival: , Order within .

The estimated shipping time is a suggestion based on current material availability. Customized orders may take up to 15 additional days for custom fabrication and material sourcing.

Why you'll love it
  1. Enhances door alignment precision
  2. Adds timeless elegance to entryways
  3. Supports heavy doors with ease
Product Specifications

Dimensions: 3.3"(8.4cm) x 4"(10.2cm)
Material: Brass
Finish: Brass, Black, Bronze
Weight Capacity: Up to 50 Kg
Pin Type: Removable Pin
Bearing Type: Plain Bearings
Installation: Mortise
Application: For Interior Use
Installation Guide

Details

Mounting Options:
 Door hinges are designed for installation on the door edge and the corresponding frame. Placement and method depend on hinge type.

Tools You May Need
  • Screwdriver (Phillips or flathead)
  • Drill and drill bits
  • Chisel (for mortising)
  • Screws
  • Tape measure and pencil
  • Level or square
  • Hammer and mallet
A. Mortise Hinges

Step 1: Mark Placement

Measure and mark hinge positions on the door edge. Standard placement is:

  • Top hinge: 5–7 inches from the top of the door.
  • Bottom hinge: 10–12 inches from the bottom.
  • Third hinge (if used): centered between top and bottom.

Step 2: Mortise the Door and Frame

Trace the hinge outline. Chisel shallow recesses into the door edge and frame so the hinge leaf sits flush.

Step 3: Pre-Drill Screw Holes

Place the hinge in the mortise, mark screw locations, and drill pilot holes.

Step 4: Attach Hinges

Screw one leaf of each hinge to the door edge. Position the door in the frame and secure the other hinge leaf to the jamb.

Step 5: Test Door Swing

Open and close the door to ensure smooth movement. Adjust screws if necessary.

B. Concealed Hinges

Step 1: Mark and Cut Recess

Mark hinge placement on both the door edge and the frame. Use a router or chisel to cut recesses deep enough to house the concealed hinge body.

Step 2: Position and Pre-Drill

Insert the hinge body into the recess, align flush with the surface, and mark screw holes. Drill pilot holes.

Step 3: Attach Hinges

Secure the hinge body into both the door and the frame using provided screws. Ensure full seating for proper alignment.

Step 4: Adjust Alignment

Most concealed hinges include adjustment screws. Use these to fine-tune door alignment vertically and horizontally.

Step 5: Test Operation

Open and close the door fully to confirm smooth, quiet motion without rubbing or binding.

Important Tips
  • Always mark hinge locations carefully before cutting or drilling.
  • Mortising ensures hinges sit flush and the door closes properly.
  • Use a level to check vertical alignment.
  • For heavy doors, use at least three hinges.
  • Periodically tighten screws to maintain performance.
Need Help?

We’re here to assist with installation or compatibility questions.
Email us at: help@residencesupply.com
Make it your own

Our in-house technicians can customize any order!

Popular Changes:

  • Hanging length
  • Material color or paint
  • Emitting color
  • Dimmable add-on
  • Add or reduce size/dimension
  • Redesign the entire lighting fixture to your suggestion

What We Do:

  • Make minor adjustments above
  • Create CAD drawings for your custom design
  • 3D render the product into your photo

Speak with an expert on live chat or call us now from 9AM EST to 6PM EST.

Alternatively, leave us an email.
Free Interior Design Consultation
Get 20% Off With Membership
See it in your room

Carvin door hinge, made from solid brass, offers durability, corrosion resistance, and a refined aesthetic. Its barrel hinge design with decorative finials ensures smooth operation, while the precision-machined knuckle enhances longevity. The eight-hole mounting plate provides secure installation for interior and exterior doors, cabinetry, and restoration projects.



FEATURES:

  • Ensures durability, corrosion resistance, and long-lasting performance.
  • With precision knuckle for effortless door movement.
  • Add a sophisticated touch to modern and classic interiors.
  • Provides secure installation and weight distribution for stability
  • Polished gold, matte black, and antique brass match any decor.

        Frequently Asked Questions

        What material is the Carvin door hinge made of?

        The Carvin door hinge is made from solid brass, ensuring durability and corrosion resistance.

        What finishes are available for this hinge?

        It comes in polished gold, matte black, and antique brass, complementing various design styles.

        Is this hinge suitable for exterior doors?

        Yes, its solid brass construction resists rust and wear, making it ideal for interior and exterior doors.

        Does the hinge support heavy doors?

        Yes, the eight-hole mounting plate provides secure weight distribution, ensuring stability for heavy-duty applications.

        Can I use this hinge for cabinetry and furniture?

        Absolutely! It’s perfect for cabinet doors, custom furniture, and restoration projects.

        Does the hinge come with screws for installation?

        Yes, it includes matching screws to ensure easy and secure installation.

        How does the barrel hinge design benefit performance?

        The precision-machined knuckle allows for smooth, frictionless movement, reducing long-term wear.

        Is this hinge compatible with modern and traditional interiors?

        Yes, its decorative finials and versatile finishes blend seamlessly with classic and contemporary spaces.

        What is the size of the hinge?

        The Carvin door hinge comes in standard sizes, suitable for most residential and commercial doors.

        Where can I buy the Carvin door hinge?

        It is available at hardware stores, online marketplaces, and specialty door hardware retailers.
